 JGGC不锈钢系列立式多级离心泵
JGGC不锈钢船用立式多级离心泵
总体数据 General Data
应 用 Application
JGGC/QDLF是一种多功能产品，可以输送从自来水到工业液体的各种不同介质，适应于不同温度、流量和压力范围，JGGC/QDL适用于无腐蚀性液体.JGGCN/QDLF适用于轻度腐蚀液体。
·供水：水厂过滤与输送，水厂分区送水、主管增压、高层建筑增压 .
·工业增压：流程水系统、清洗系统、高压冲洗系统、消防系统 .
·工业液体输送 :冷却和空调系统、船舶工业、锅炉给水和冷凝系统、机床配套、酸和碱.
·水处理 :超滤系统、反渗透系统、蒸馏系统、分离器、游泳池.
·灌溉 :农田灌溉、喷灌、滴灌.
JGGC/QDLF is a kind of multifunctional products. It can be used to convey various mediums from tap water to industrial liquid at different temperature and with different flow rate and pressure. JGGC/QDL type is applicable to conveying non-corrosive liquid, white JGGCN/QDLF is suitable for slightly corrosive liquid.
· Water supply: Water filter and transport in
Waterworks, boosting of main pipeline, boosting in high-rise buildings.
· Industrial boosting: Process flow water system, cleaning system, high-pressure washing system, and fire fighting system.
· Industrial liquid conveying: Pump For Marine Cooling and air-conditioning system, boiler water supply and condensing system, machine-associated purpose, acids and alkali,
· Water treatment: Ultra filtration system, reverse osmosis system, distillation system, separator, swimming pool
· Irrigation: Farmland irrigation, spray irrigation, dripping irrigation
运行条件 Operation conditions
·稀薄 、干净、非易燃并不含固体颗粒或纤维的液体 .
Thin, clean, non-flammable and non-explosive liquid containing no solid granules and fibers
·液体温度 Liquid temperature :
常温型 Normal temperature type : -15℃一+70℃
热水型 Hot water type : +70℃一+120℃
·环境温度 Ambient temperature : 最高 up to +40℃
·海拔 Altitude : 最高 up to 1000m
泵 Pump
JGGC/QDLF为安装标准电机的非自吸立式多级离心泵,电机轴通过泵头用联轴器直接与泵轴联接,拉杆螺栓将耐压筒 、过流部件固定在泵头和进出水段之间 ,泵进出水口在泵底同一直线上;本泵可根据需要配置智能保护器,对泵干转、缺相、过载等进行有效保护.
JGGC/QDLF is a kind of vertical non–self-priming multistage centrifugal pump, which is driven by a standard electric motor. The motor output shaft directly connects with the bet pump shaft through a coupling.
The pressure-resistant cylinder and flow passage components are fixed between pump head and in-and Outlet section with tie-bar bolts the inlet and outlet is Located at the pump bottom at the same plane. This Kind of pump can be equipped with an intelligent protector to effectively prevent it from dry running,
Out-of-phase and overload.
船用水泵 Pumps for Marine
我厂产品 ,采用Y-H型船用电机驱动,通过中国船级社形式认可,可与船用产品配套,作为船用泵或船用锅炉给水泵,船用消防泵.
Our product driven by Y-H marine motor is approved by China classification society that It is suitable to match with marine product as a boiler feed pump of for other use .
防爆电泵 Explosion-proof Electric Pumps
产品配不同等级防爆电机,用于各种要求防爆场所
Our product driven by YB type explosion-proof motor is suitable for various class explosion dangerous environments.
电 机 Electric motor
·电机为全封闭 ,风冷式二级标准电机.
Full-enclosed air-blast two-pole standard motor
·防护等级 protection class : IP55
·绝缘等级 Insulation class : F
·标准电压 Standard voltage : 50Hz :1× 220-230/240V
3 × 200-220/346-380V
3 × 220-240/380-415V
3 × 380-415V
60Hz :3 × 200-230/346-400V
3 × 220-255/380-440V
3 × 220-277/380-480V
JGGC / QDLF 0.6系列不锈钢立式多级离心泵
JGGC / QDLF 0.6 Vertical Multistage Centrifugal
Pump
|
型号
Model |
级数
Stages |
电压Standard voltage:50Hz
380V
转速n:Speed(r/min)2900 |
电压Standard voltage:60Hz
440V
转速n:Speed(r/min)3500 |
最大
效率 |
|
流量(Q)
Rated flow |
扬程(H)
Pressure |
电机
Motor |
流量(Q)
Rated flow |
扬程(H)
Pressure |
电机
Motor |
efficiency |
|
n |
m3/h |
l/s |
m |
kw |
m3/h |
l/s |
m |
kw |
% |
|
JGGC0.6
QDLF0.6
|
2 |
0.3
0.6
0.8 |
0.08
0.16
0.22 |
17
16
14.6
|
0.55 |
0.36
0.72
0.96 |
0.10
0.19
0.26 |
24.9
22.9
20.9 |
0.75 |
12.5
18
22 |
|
3 |
0.3
0.6
0.8 |
0.08
0.16
0.22 |
25.5
24
21.9 |
0.55 |
0.36
0.72
0.96 |
0.10
0.19
0.26 |
36.4
34.3
31.3
|
0.75 |
12.5
18
22 |
|
4 |
0.3
0.6
0.8 |
0.08
0.16
0.22 |
34
32
29.2
|
0.55 |
0.36
0.72
0.96 |
0.10
0.19
0.26 |
48.6
45.7
41.7
|
0.75 |
12.5
18
22 |
|
5 |
0.3
0.6
0.8 |
0.08
0.16
0.22 |
42.5
40
36.5
|
0.75 |
0.36
0.72
0.96 |
0.10
0.19
0.26 |
60.7
57.1
52.1
|
1.1 |
12.5
18
22 |
|
6 |
0.3
0.6
0.8 |
0.08
0.16
0.22 |
51
48
43.8
|
0.75 |
0.36
0.72
0.96 |
0.10
0.19
0.26 |
72.9
68.6
62.6
|
1.1 |
12.5
18
22 |
|
7 |
0.3
0.6
0.8 |
0.08
0.16
0.22 |
59.5
56
51.1
|
0.75 |
0.36
0.72
0.96 |
0.10
0.19
0.26 |
85
80
73
|
1.1 |
12.5
18
22 |
|
8 |
0.3
0.6
0.8 |
0.08
0.16
0.22 |
68
64
58.4
|
1.1 |
0.36
0.72
0.96 |
0.10
0.19
0.26 |
97.1
91.4
83.4 |
1.5 |
12.5
18
22 |
|
9 |
0.3
0.6
0.8 |
0.08
0.16
0.22 |
76.5
72
65.7
|
1.1 |
0.36
0.72
0.96 |
0.10
0.19
0.26 |
109.3
102.9
93.9 |
1.5 |
12.5
18
22 |
|
10 |
0.3
0.6
0.8 |
0.08
0.16
0.22 |
85
80
73
|
1.1 |
0.36
0.72
0.96 |
0.10
0.19
0.26 |
121.4
114.3
104.3 |
1.5 |
12.5
18
22 |
|
11 |
0.3
0.6
0.8 |
0.08
0.16
0.22 |
93.5
88
80.3
|
1.1 |
0.36
0.72
0.96 |
0.10
0.19
0.26 |
133.6
125.7
114.7
|
1.5 |
12.5
18
22 |
|
12 |
0.3
0.6
0.8 |
0.08
0.16
0.22 |
102
96
87.6
|
1.1 |
0.36
0.72
0.96 |
0.10
0.19
0.26 |
145.7
137.1
125.1
|
2.2 |
12.5
18
22 |
|
13 |
0.3
0.6
0.8 |
0.08
0.16
0.22 |
110.5
104
94.9
|
1.5 |
0.36
0.72
0.96 |
0.10
0.19
0.26 |
157.9
148.6
135.6
|
2.2 |
12.5
18
22 |
|
14 |
0.3
0.6
0.8 |
0.08
0.16
0.22 |
119
112
102.2
|
1.5 |
0.36
0.72
0.96 |
0.10
0.19
0.26 |
170
160
146
|
2.2 |
12.5
18
22 |
|
15 |
0.3
0.6
0.8 |
0.08
0.16
0.22 |
127.5
120
109.5 |
1.5 |
0.36
0.72
0.96 |
0.10
0.19
0.26 |
182.1
171.4
156.4 |
2.2 |
12.5
18
22 |
|
16 |
0.3
0.6
0.8 |
0.08
0.16
0.22 |
136
128
116.8 |
1.5 |
0.36
0.72
0.96 |
0.10
0.19
0.26 |
194.3
182.9
166.9
|
2.2 |
12.5
18
22 |
|
17 |
0.3
0.6
0.8 |
0.08
0.16
0.22 |
144.5
136
124.1 |
1.5 |
0.36
0.72
0.96 |
0.10
0.19
0.26 |
206.4
194.3
177.3
|
3 |
12.5
18
22 |
|
18 |
0.3
0.6
0.8 |
0.08
0.16
0.22 |
153
144
131.4 |
2.2 |
0.36
0.72
0.96 |
0.10
0.19
0.26 |
218.6
205.7
187.7
|
3 |
12.5
18
22 |
|
19 |
0.3
0.6
0.8 |
0.08
0.16
0.22 |
161.5
152
138.7 |
2.2 |
0.36
0.72
0.96 |
0.10
0.19
0.26 |
230.7
217.1
198.1
|
3 |
12.5
18
22 |
|
20 |
0.3
0.6
0.8 |
0.08
0.16
0.22 |
170
160
146 |
2.2 |
0.36
0.72
0.96 |
0.10
0.19
0.26 |
242.9
228.6
208.6
|
4 |
12.5
18
22 |
|
21 |
0.3
0.6
0.8 |
0.08
0.16
0.22 |
178.5
168
153.3 |
2.2 |
0.36
0.72
0.96 |
0.10
0.19
0.26 |
255
240
219
|
4 |
12.5
18
22 |
|
22 |
0.3
0.6
0.8 |
0.08
0.16
0.22 |
187
176
160.6 |
2.2 |
0.36
0.72
0.96 |
0.10
0.19
0.26 |
267.1
251.4
229.4 |
4 |
12.5
18
22 |
汽蚀余量(NPSH)r:2m
叶轮直径(D.of lmpel)φ：95mm |
