概述: CLH系列立式海水泵系列按照CB/T3523—93《船用立式海水泵》及有关ISO国际标准自行设计的一种新型离心泵，分二个系列。适用于各种船舶、军舰作为压载泵、舱底泵、冷却泵、排水泵、消防泵, 亦可作为海水淡化装置及各种水柜装置作配套给水泵，以及石油化工管道、冷热水循环系统及高层建筑生活用水的增压泵。 (系列Ⅰ)
二、主要技术性能参数:
|
型 号 |
流量 m3/h |
扬程 m |
配用功率 Kw |
转速 r/min |
(NPSH)r m |
CLH25-25-6.5(Z) |
3 |
8 |
0.37 |
2950 |
4.0 |
CLH40-32-2(Z) |
5 |
45 |
3 |
4.0 |
CLH40-32-2.5(Z) |
10 |
60 |
5.5 |
4.0 |
CLH40-32-3(Z) |
10 |
45 |
4.0 |
4.0 |
CLH40-32-3.5(Z) |
5 |
25 |
1.5 |
4.0 |
CLH40-32-5(Z) |
10 |
25 |
2.2 |
4.0 |
CLH50-32-2(Z) |
12.5 |
8 |
11 |
3.0 |
CLH50-32-3(Z) |
12.5 |
65 |
7.5 |
3.0 |
CLH50-32-3.5(Z) |
12.5 |
50 |
5.5 |
3.0 |
CLH50-32-4.5(Z) |
12.5 |
32 |
3 |
3.0 |
CLH50-32-6.5(Z) |
12.5 |
20 |
2.2 |
2.5 |
CLH50-40-7(Z) |
20 |
25 |
4 |
4.0 |
CLH50-50-4.5(Z) |
20 |
45 |
5.5 |
4.0 |
CLH65-40-2.5(Z) |
25 |
110 |
22 |
3.0 |
CLH65-40-3(Z) |
25 |
80 |
15 |
4.0 |
CLH65-40-4(Z) |
25 |
65 |
11 |
4.0 |
CLH65-40-4.5(Z) |
25 |
50 |
7.5 |
3.0 |
CLH65-50-6.5(Z) |
25 |
32 |
5.5 |
3.0 |
CLH65-50-8.5(Z) |
30 |
25 |
5.5 |
4.0 |
CLH65-50-9(Z) |
25 |
20 |
3 |
3.0 |
CLH65-65-5.5(Z) |
30 |
45 |
7.5 |
4.0 |
CLH80-50-3.5 |
50 |
125 |
37 |
3.0 |
CLH80-50-4 |
60 |
85 |
30 |
4.0 |
|
CLH80-50-5 |
50 |
65 |
18.5 |
|
3.0 |
CLH80-50-6.5 |
50 |
50 |
15 |
3.0 |
CLH80-50-7(Z) |
50 |
45 |
15 |
3.5 |
CLH80-65-5.5(Z) |
50 |
60 |
18.5 |
3.5 |
CLH80-65-9(Z) |
50 |
32 |
7.5 |
2.5 |
CLH80-65-11(Z) |
50 |
25 |
7.5 |
3.5 |
|
| CLH80-65-13(Z) |
50 |
20 |
5.5 |
2950 |
2.5 |
| CLH100-65-5 |
100 |
125 |
75 |
5.0 |
| CLH100-65-5.5 |
100 |
100 |
55 |
4.8 |
| CLH100-65-7(Z) |
70 |
60 |
22 |
4.0 |
| CLH100-65-8 |
100 |
60 |
30 |
4.5 |
| CLH100-65-9A |
80 |
40 |
18.5 |
4.0 |
| CLH100-65-10(Z) |
100 |
45 |
22 |
4.5 |
| CLH100-80-6 |
100 |
90 |
45 |
5.0 |
| CLH100-80-6.5 |
100 |
80 |
37 |
4.5 |
| CLH100-80-13(Z) |
70 |
25 |
11 |
4.0 |
| CLH100-80-13 |
100 |
32 |
15 |
4.0 |
| CLH100-80-19(Z) |
100 |
20 |
11 |
3.0 |
| CLH100-100-8.5(Z) |
70 |
45 |
18.5 |
4.0 |
| CLH125-80-6 |
160 |
125 |
90 |
5.8 |
| CLH125-80-7 |
160 |
100 |
75 |
5.2 |
| CLH125-80-8 |
160 |
80 |
55 |
4.8 |
| CLH125-80-10 |
160 |
65 |
45 |
4.2 |
| CLH125-100-6.5 |
150 |
110 |
75 |
5.0 |
| CLH125-100-10 |
125 |
20 |
11 |
1450 |
4.5 |
| CLH125-100-11 |
160 |
65 |
45 |
2950 |
5.0 |
| CLH125-100-12(Z) |
150 |
45 |
37 |
5.5 |
| CLH125-100-12 |
160 |
50 |
37 |
4.0 |
| CLH125-100-13 |
200 |
50 |
45 |
4.5 |
| CLH125-100-17(Z) |
120 |
25 |
15 |
5.5 |
| CLH125-100-17 |
160 |
32 |
22 |
3.7 |
| CLH125-100-19 |
200 |
32 |
30 |
3.5 |
| CLH125-100-23 |
160 |
20 |
15 |
3.5 |
| CLH125-125-7 |
120 |
80 |
45 |
4.0 |
| CLH150-125-4 |
265 |
86 |
110 |
1450 |
4.5 |
| CLH150-125-6 |
300 |
62 |
75 |
5.5 |
| CLH150-125-10 |
250 |
32 |
37 |
7.5 |
| CLH150-125-22(Z) |
200 |
25 |
22 |
2950 |
7.0 |
| CLH200-150-12 |
320 |
32 |
45 |
1450 |
5.0 |
| CLH250-200-19 |
600 |
25 |
75 |
3.7 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
